Run multiple accessories off with this convenient water resistant hub. Connect your amplifier and accessories to power and ground with fuse protection. This makes it safe and simple to add amplifiers, LED lights, electronic coolers, navigation, lighting and more to your boat or machine. The sealed unit features water resistant gaskets which prevent water intrusion into the terminals sealing every aspect of the unit.
IPX5 Marine grade construction
Compact distribution block design
Sturdy screw-in terminals
High temperature heavy duty transparent protective cover
PRIMARY DISTRIBUTION:
2 – POS 0/4 gauge input
2 – POS 4/8 gauge AFS fused output (sealed)
1 – NEG 0/4 gauge input
2 – NEG 4/8 Gauge output (sealed)
SECONDARY DISTRIBUTION:
POS 4 ATC Fused outputs
Ring terminal connections
Individual seal up to 14 gauge
NEG 4 outputs
Ring terminal connections
Individual seal up to 14 gauge
Also Included:
Extra ATC fuse holder location
Torx® Wrench included and can be stored on the inside of the cover
| DBLOCKPGM | ||
| Wire Gauge | Quantity | |
| Inputs | Three 1/0 AWG | 2 |
| Outputs | Four 4/8 AWG | 4 |
- bchandlingtime:
- 1
1 Year
