MSD IGNITION

Msd Ignition Gm Ls Ignition Controller - Red

$509.95
Write a Review
SKU:
MSD6014
UPC:
085132060146
Condition:
New
Availability:
Usually ships within 24 hours.
Shipping:
Free Shipping
  • Free Ground Shipping

  • 30-Day Returns

  • Safe Payments

  • Top Tier Brands

The MSD 6014 LS Ignition controller is designed to seamlessly work with both 24x/1x and 58x/4x crank/cam configurations. Its innovative auto-detection feature identifies the correct configuration based on the reluctor wheel pattern, eliminating the need for manual selection. The controller offers six pre-programmed (non-editable) timing tables for stock engines, along with three customizable 3-D tables and one customizable timing plot. Switching between these tables/plots is effortless using the rotary dial, and customization can be done through the MSDView software.

Featuring a built-in 2.5 Bar MAP sensor, the LS Ignition controller is suitable for naturally aspirated or boosted applications, allowing for precise timing adjustments based on intake manifold pressure. Additionally, it incorporates 8MB of internal data logging, enabling users to set up, record, and review performance data at the track.

As the demand for a robust ignition system for GM LS engines grows, MSD meets this demand with an enhanced version of the popular 6LS box. Whether working with a stock crate engine or a custom powerhouse, the MSD LS Ignition provides the control needed for optimal performance. Adjusting timing curves is made easy with preset options or customizable setups using the MSD View software. New features include high-speed data acquisition, optional coolant temperature sensor input, idle timing control, and individual cylinder timing, in addition to existing features like programmable step retard, launch retard, and RPM rev limiters.

Features:

  • Compatible with most LS Engines
  • Basic functionality without the need for a PC
  • Six preprogrammed timing tables for quick setup
  • Rotary selector switch for on-the-fly timing changes
  • Nitrous and boost compatibility
  • High-speed data acquisition
  • Fully sealed direct plugin connectors
  • Programmable step retard
  • Launch and max rev limiters
  • Optional coolant temperature sensor input
  • Launch retard
  • Idle timing control
  • Individual cylinder timing
  • Compatible with MSD, Accel, and GM LS coils
