Upgrade your C10's rear suspension with QA1's Bolt-On Rear Suspension System, specially designed for trucks originally equipped with a coil-spring rear suspension. This innovative system brings coil-over performance to your C10, offering up to 6" of total drop for a sleek and aggressive stance.
One of the standout features of this system is its adjustability, allowing you to fine-tune the geometry for optimal performance after lowering. By converting to adjustable coil-overs, you gain the flexibility to set the ride height for each corner independently, achieving that perfect, customized stance for your C10.
The tubular steel truck arms in this system feature integrated pinion angle adjustment, eliminating the need for angled shims. This not only simplifies the setup but also allows you to set the wheelbase to exact specifications. The adjustable panhard bar ensures that the rear stays centered, providing more predictable cornering performance.
Roll center geometry is corrected based on the amount of drop, thanks to multiple mounting locations, enhancing overall handling and control. The coil-overs are strategically relocated to the outside of the frame rail, closer to the wheel, promoting better cornering stability. This design also creates space for popular aftermarket rear-mounted fuel tanks.
Ease of installation is a key feature of QA1's Bolt-On Rear Suspension System. It can be easily bolted on, and the entire rear system can be installed without the need to remove the bed of the truck. Upgrade your C10's rear suspension to experience the benefits of coil-over performance and achieve the perfect balance of style and handling.
