Holley's EFI Crank Trigger Kit is meticulously crafted to deliver a precise crank speed and position signal to Holley EFI systems, tailored for the most demanding high-horsepower racing applications. Unlike standard 4-Magnet, MSD "style" Crank triggers that measure crank position every 45 degrees, this kit ensures accuracy with measurements taken every 10 degrees. It is specifically engineered for application on Small Block Ford (SBF) engines using a standard ATI or Fluidamper "style" balancer up to 7-1/4" in diameter.
Key Features:
- 7.25” diameter, 1/4” thick, billet steel, 36-1 tooth crank wheel with Black Zinc Oxide finish, providing superior corrosion resistance and an impressive aesthetic.
- Crank wheel centers off the balancer’s hub, eliminating the need for a centering ring.
- All billet, 6061-T6 aluminum sensor mounting brackets featuring a "bright-dipped" black anodized finish and Laser-etched Holley EFI logo.
- Custom 3-wire, ferrous-target, Hall-effect sensor with M12X1mm threads for finer gap adjustment.
- Includes Grade 8 and Mil. Spec mounting hardware for robust and secure installation.
